Wagner Tuning Ford Focus RS 2.3L EcoBoost MK3 Competition Intercooler Kit - 200001090

Wagner Tuning Ford Focus RS 2.3L EcoBoost MK3 Competition Intercooler Kit - 200001090

This High Performance Intercooler has the following core size (630mm x 215mm x 125mm = 16.931cm³) offering a 10% larger frontal area and 72% more charge air volume compared to the original intercooler.

Our engineers have increased the intercooler core size and efficiency, as well as improved the end tank design to remove any OEM bottlenecks, resulting in increased flow and charge air cooling properties. Competition Intercooler core with turbulators (weighing  9.2kg). Constructed using the highest quality Tube and Fin intercooler core combined with cast aluminium end tanks optimized in CAD. Flow analyses and simulations were created to optimise the design for best possible internal airflow. We have also increased inlet and outlet connections to 70mm diameter.

This intercooler is protected by an Anti-Corrosion coating with perfect thermal heat dissipating character.

Dimensions stock Intercooler:
615mm x200mm x 80mm
Core Volume=9.84L
Frontal Area=1230cm²

Dimensions Wagner Tuning Intercooler:
630mm x 215mm x125mm
Core Volume=16.9L
Fontal Area=1355cm²

This Intercooler Kit Suits:

Ford Focus RS MK3 2.3L EcoBoost 2016-2018

Package Includes:

• 1 Intercooler
• 2 Silicone Hoses
• 1 Mounting Material
• 1 Installation instructions
