Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144
Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144
Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144
Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144
Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144

Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144

$3,309.00

Wagner Tuning BMW F20 F30 N55 ONLY M135i M235i M2 1 Series 3 Series 4 Series Competition EVO3 Intercooler Kit - 200001144

The BMW Competition Intercooler Kit EVO3 has the following core dimensions 510mm x 345mm x 180mm / stepped & Volume of 23,56L

The high performance intercooler core provides a 165% larger frontal area and 223% more volume compared to the stock mounted intercooler. Our engineers have increased the intercooler core size and efficiency, as well as improved the endtank design to remove any OEM bottlenecks, resulting in increased flow rating and charge cooling properties.

We use our award winning Wagner Tuning Competition Intercooler Core which is made specifically for this application. Constructed of the highest quality Tube Fin intercooler cores with inside turbulators combined with cast aluminum endtanks optimized by CFD for best possible internal airflow. The stock click connections have been eleminated and increased to a connection diameter of 65mm for inlet and 76mm for outlet, so this kit comes with reinforced silicone hoses as well as 3 aluminum chargepipes.

The result is excellent cooling properties and a lot less pressure drop then the stock intercooler. Despite of it´s size the weight of the complete intercooler is only 13.8kg. This Intercooler Kit is the best choice when it comes to performance gains and low intake temperatures and also the right thing for racing.

  • Less pressure drop then stock intercooler.
  • Maximum cooling performance with clearly more power.
  • Anti corrosion protective coating with perfect thermal heat dissipating character.
  • Plug & Play Installation
  • All of Wagner products undergo rigorous quality control.
  •

    Dimensions stock intercooler:
    510mm x 130mm x 110mm
    V=7.3 Litres
    A=663 cm²

    Dimensions Wagner Tuning Intercooler:
    510mm x 345mm x 180mm  [stepped]
    V=23.56 Liitres
    A=1759.5 cm²

    This Intercooler Kit Suits N55 Models ONLY:

    • BMW M135i F20 / F21 235-240KW/320-326PS (2011-2016)
    • BMW M235i F22/F23 240KW/326PS (2014-2016)
    • BMW M2 F87 272KW/370PS (2016+)
    • BMW 335i F30 / F31 / F34 235KW/320PS (2011-2015)
    • BMW 435i F32 / F33 / F36 225KW/306PS (2013-2016)



    Package Includes:

    • 1 Intercooler
    • 1 76mm charge pipe
    • 1 External Air Shroud
    • 2 Silicone Hoses
    • 1 Aluminium cross member
    • 1 Mounting Material
    • 1 Installation instructions
